J.M. Calvagno, R.N. Tomezzoli,,E.O. Cristallini, M.B. Febbo, L.C. Gallo, F. Copertini
2 019
Latinmag Letters, Volume 9, Special Issue (2019), C06-O, 1-6. Proceedings Rancagua, Chile
La anisotropía de susceptibilidad magnética (AMS) es un método preciso para conocer la fábrica magnética
y permite conocer la ubicación espacial de los esfuerzos regionales en áreas deformadas. La relación entre
el elipsoide de AMS y su coaxialidad con el elipsoide de esfuerzos y deformación es conocida, donde el eje
menor de AMS (Kmin) coincide con la dirección del esfuerzo principal σ1. A partir de la medición de la
susceptibilidad magnética y la interpretación de la fábrica magnética interna de modelos análogos de arena,
se puede hacer una aproximación sobre la distribución de los esfuerzos en zonas de deformación. Aquí
presentamos los resultados de tres modelos análogos con diferentes mineralogías magnéticas. Los modelos
se realizaron con el objetivo de evaluar la susceptibilidad magnética en diferentes posiciones del modelo
y calcular el elipsoide de AMS y la relación entre la fábrica magnética y la mineralogía magnética, para
comparar cuáles de las diferentes mineralogías son las mejores para los modelos posteriores.
Anisotropy of magnetic susceptibility (AMS) is a precise method to know the magnetic fabric and allows to
know the spatial location of regional stresses in deformed areas. The relationship between the ellipsoid of
AMS and its coaxiality with the ellipsoid of stress and deformation is known, where the minor axis of AMS
(Kmin) coincides with the direction of the main stress σ1. From the measurement of magnetic susceptibility
and the interpretation of the internal magnetic fabric of analogous sand models, an approximation can be
made to the knowledge of the distribution of stress in deformation zones. Here we present the results of
three analogues models with different magnetic mineralogies. They were performed with the objective of
evaluating the magnetic susceptibility in different positions of the model and calculate the AMS ellipsoid
and the relationship between the fabric obtained and the magnetic mineralogy, to compare which of the
different mineralogies are the best to subsequent models.

http://www.geofisica.unam.mx/LatinmagLetters/LM19-0101SP/C-O/C.06-O.pdf
